ADJ 2.9mm LED Video Wall Panel
The AV2 is a high resolution, flexible video panel from ADJ. Each panel has a pixel pitch of 2.97mm with a configuration of a 3-in-1 RGB SMD2121 LED. The panel can curve in convex or concave +/-5. The brightness is 1000 NITS. There are 4 LED modules per panel. This allows for easy serviceability. The AV2 connections include powerCon In/Out and Ethercon In/Out. This panel also features a Novastar A5s receiving card.
Features:
- Pixel Pitch: 2.97mm (0.17″)
- LED Configuration: 3-in-1 SMD2121 LED
- Pixel Density: 168×168; 112896 per square meter
- Module Quantity: 4
- Surface Flatness: Gaps<0.5mm
- Brightness: 1000 NITS
- View Angle: Horizontal 160/Vertical up 60 down 60 @ 9.75 ft. (2.97m)
- Gray Scale / Display Color: 14-bit
- Brightness Adjustment: 0~100% 100 Levels
- Processing: 14-bit
- Operation Power: 100~240V 50-60Hz
- Max. Power Consumption: 115W/per panel
- Ave. Power Consumption: 35W/per panel
- Connections Power/Data: Power-PowerCon In/Out; Data EtherCon In/Out
- Control Mode: Nova Star Synchronous System with Control via DVI
- Frame Update Frequency: 50-60Hz
- Scan Mode: 1/21
- Refresh Rate: ?1920Hz
- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
- Control Distance: Ethernet Cable <100m or Fiber Optic>120m
- Support VGA Mode: 1024 x 768, 1280 x 1024, 1600 x 1200, 1920 x 1280
- Brightness Correction: Pixel, Module, Cabinet
- Operating Temp / Humidity: Fahrenheit: -4 + 104 / Celsius: -20 + 40/ 10-90% (No Condensation)
- Operating Life / MTBF: 50,000 Hours / 5,000 Hours
- Protection Level: IP20 (Front and Back)
- Out of Control Rate: <0.02%
- Size: 19.75″ x 19.75″ x 3″ / 500 x 500 x 73mm
- Weight: 17.64 lbs. / 8kg.
