ADJ American DJ AX2100 Aria X2 Transceiver with Wired Digital Communication Network
Introducing the Aria Wireless Management System for Advanced Lighting Control at the Shop or in the Show. Aria, the next evolution in wireless lighting management, poised to revolutionize your experience with unmatched control, efficiency, and simplicity. This advanced system leverages state-of-the-art technology to present a solution that flexes with your requirements, delivering a seamless lighting encounter, whether on-site or behind the scenes.
Features:
- Single DMX Universe
- 900Mhz., 2.4 GHz WiFi and Bluetooth
- Configuration via App (Coming Soon) or Front panel
- Wireless to DMX or DMX to Wireless
Specifications:
- Supported Protocols:
- DMX
- RDM (Planned for future software release)
- Proprietary 802.15.4:
- Bluetooth 5.2 (BLE)
- Aria X2 Serial Protocol:
- This is our proprietary serial protocol for communicating with a variety of fixtures.
- RF Characteristics:
- Frequency range:
- 2404-2480 MHz
- 863-870 MHz (EU)
- 902-928 MHz
- Radio module: Aria X2
- Interference mitigation:
- CSMA
- Adaptive frequency hopping (on the roadmap)
- OTA updates
- Connectors:
- Antenna: 5G JT SMA
- DMX: 5-pin XLR Input and Output
- DC: 2.5mm/5.5mm Barrel connector
- Outdoor Locking Power Input and Output
- Power:
- AC100-240V 50/60Hz
- Power Consumption: 2W
- Power Fuse: T1.25A/250V. (5 x 20mm)
- Physical:
- IP20 Aluminum / Metal enclosure
- Front panel digital screen and rotary knob
- M10 and M12 Threads
- Safety Eyelet
- Max ambient operating temp: 113F (45C)
- Max operating humidity: <75%
- Storage temperature: 77F (25C)
- Rack and wall mount accessories
- Dimensions and Weight:
- Length: 6.46″ (163.95mm)
- Width: 8.48″ (215.30mm)
- Height: 1.66″ (42mm)
- 2.7lbs (1.23kgs.)
