ADJ American DJ VS2-9X5 ArKaos Video Panel System with 45x VS2 LED Panels

ADJ American DJ VS2-9X5 ArKaos Video Panel System with 45x VS2 LED Panels

ADJ Video Panel System featuring 28 ADJ VS2, 2.97mm pixel pitch video panels, power cables, data cables, rigging bars, video processor and software.

Features:

• Video Panel System Includes:
  • 45 x VS2 2.97mm Pixel Pitch Video Panels (VS2001)
  • 44 x 3-foot Panel to Panel Data Cables (CAT113)
  • 1 x 25-foot First Data Cable (CAT451)
  • 39 x 3-foot Locking In/Out Power Cables (SPL013)
  • 6 x 15-foot Locking In/Out Main Cables (SMP027)
  • 1 x Novastar VX400 Video Processor (VX4027)
  • 1 x ArKaos Media Master Express Software
  • 9 x VSRB1 Vision Series Rigging Bars (VS1100)

Specifications:

• American DJ VS2 Vision Series High-Resolution Video Panel Specs:
  • Display:
    • Display Size: 19.68″
    • Panel Type: LCD
    • Display Orientation: Landscape, Portrait
    • Native Resolution: 168 x 168
    • Maximum Brightness: 1000 nits / cd/m
    • HDR Support: No
    • Dynamic Contrast Ratio: 5000:1
    • Refresh Rate: 75 Hz
    • Viewing Angle (H x V): 160 x 140
    • Screen Area: 19.69 x 19.69″ / 500 x 500 mm
  • Video:
    • TV Tuner: No
  • Connectivity:
    • Outputs: No
    • Wireless: No
    • NFC: No
    • USB I/O: No
    • Ethernet I/O: Rear: 2x RJ45 (Unspecified Ethernet)
    • Ambient Light Sensor: No
  • Speaker:
    • Built-In Speakers: No
  • Hardware:
    • Mobile App Compatible: No
    • Media Card Reader: No
    • Built-In Mic: No
  • Electrical:
    • Power Consumption: Maximum: 170.0 W, Typical: 68.0 W
    • Input Power: 100 to 240 VAC, 50 / 60 Hz
    • Power Adapter Type: Internal
  • General:
    • Operating Conditions: -4 to 104F / -20 to 40C at 10 to 90% Humidity
    • Certifications: cETLus
    • Lighting Lifespan: 50000 Hours
    • Environmental Resistance: Dust-Resistant (IP20)
    • Dimensions: 19.7 x 19.7 x 2.7″ / 500 x 500 x 69.6 mm
    • Weight: 16.98 lb / 7.7 kg
• American DJ Powerlock Connector Link Cable, 3′ Specs:
  • General:
    • Connector 1: powerCON
    • Connector 2: powerCON
    • Cable Length: 3′ / 0.91 m
• American DJ Locking Power Cable to Edison Cable, 15′ Specs:
  • General:
    • Connector 1: powerCON
    • Connector 2: NEMA 5-15
    • Cable Length: 15′ / 4.57 m
• American DJ VSRB1 Single Panel Rigging/Ground Stack Bar for Vision Series LED Panels Specs:
  • Licensing:
    • Dimensions: Not Specified by Manufacturer
    • Weight: Not Specified by Manufacturer
• Elation Professional ArKaos Media Master Express Software Package Specs:
  • General:
    • Category: Creativity application – video editing & production
    • Product Type: License
    • Platform: Windows, MacOS
  • Licensing:
    • License Type: 1 license
