AJA 3GDA 1×6 3G/HD/SD Reclocking Distribution Amp

AJA 3GDA 1×6 3G/HD/SD Reclocking Distribution Amp

The 3GDA is a miniature, low cost 1×6 3G HD-SDI/HD-SDI/SDI reclocking distribution amplifier. Featuring six separately buffered SDI outputs, the 3GDA provides automatic input detection, reclocking, and cable equalization.

Features:

• Compact SD/HD distribution
• Six separately buffered outputs
• 3G/HD/SD-SDI input, auto sensing
• 3G cable equalization (1694 coax)
• SD: 270mb, 350m, HD: 1.5Gb, 200m
• Passes all ancillary data test

Specifications:

• Video Formats: 100 Mbps – 3 Gbps, format agnostic
• Video Input Digital: 1 x 3G-SDI BNC, SMPTE-259/292/424
• Video Output Digital: 6 x 3G-SDI BNC, SMPTE-259/292/424
• Cable Equalization(Belden 1694A coax)
  • 3 Gbps, 120m
  • 1.5 Gbps, 200m
  • 270 Mbps, 350m
• Input / Output Return Loss: >15db, 270 Mb – 3 Gb
• Reclocking
  • 2.970 Gbps, 2.967 Gbps, 1.485 Gbps, 1.483 Gbps, 270 Mbps – Auto Select
  • All other rates are passed through and not reclocked
• Size (w x d x h): 5.8″ x 3.1 x 1″ (131mm x 79mm x 25mm)
• Weight: 0.7 lbs. (0.3 kg)
• Power:
  • +5-18VDC, regulated, 3 watts, power supply required, included with purchase
  • AC Adapter: 100-240VAC, 50/60 Hz, universal input
• Environment:
  • Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
  • Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140 degrees F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)
