AJA FIDO-2R 2-Channel Single Mode LC Fiber/3G-SDI Receiver
FiDO-2R offers unmatched flexibility and cost efficiency for SDI-Fiber conversion, allowing for long cable runs up to 10 km (32,808 ft) with electrical isolation – useful for eliminating ground loop problems. FiDO converters use a compact, low profile enclosure that works well in tight spaces around and behind equipment racks, trucks, and on camera.
Features:
- 2-Channel Single Mode LC Fiber to 3G-SDI Receiver
- Duplex connection (LC connector)
- Dual, independent 3G/HD/SD-SDI outputs
- Both Fiber-to-SDI paths are completely independent
- Uses 5-20VDC power (DWP-U-R1 universal power supply included)
Specifications:
- Video Formats: 150 Mbps – 3 Gbps, format agnostic
- Video Input Digital:
- 2-Channel independent Single Mode LC Fiber Outputs, SMPTE-297
- Nominal Wavelength: 1260 – 1620 nm
- Optical Sensitivity: -18 dBm (min)
- Overload Power: -3 dBm (min)
- Video Output Digital: 2-Channel independent 3G-SDI BNC Outputs, SMPTE-259/292/424
- Reclocking:
- 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps – Auto Select
- All other rates are passed through and not reclocked
- Size (w x d x h): 4.6″ x 1.71 ” x.85″ (117 x 43.5 x 21.6mm)
- Weight: 0.5 lb (0.3 kg)
- Power:
- 3 watts max
- Uses 5-20VDC power (AJA power supply model DWP-U-R1 included)
- Environment:
- Safe Operating Temperature: 0 to 40 C (32 to 104 F)
- Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
- Operating Relative Humidity: 10-90% noncondensing
- Operating Altitude: <3,000 meters (<10,000 feet)
