AKG CBL201 Dual Element Professional Low-Profile Boundary Layer Microphone

AKG CBL201 Dual Element Professional Low-Profile Boundary Layer Microphone

The AKG CBL201 is easy to install with intuitive user controls. Leveraging AKGs vast portfolio of innovation, the new CBL Series by AKG is a family of low-profile boundary layer microphones, available in multiple form factors and mic coverage patterns to accommodate critical applications including conference rooms and meeting spaces. Featuring intuitive user controls for talk/mute, elegant design aesthetics with LEDs, and screw terminals for mics and I/O, the CBL Series is easy to install, easy to use, easy on the eyes and makes meetings sound great.

Features:

• Low Profile: Minimally disrupts the table surface
• Triple Element Cardioid Microphone: User-configurable from 270 to 360
• Screw Terminals: Greatly simplify installation
• Touch I/O: Change talk and mute state by simply touching the mic
• RGB Led Ring Indicators: Red, green, and blue LEDs provide clear visual cues to indicate current talk and mute state
• RF Interference Suppression: Avoid interference from mobile phones and laptops
• Elegant Design: Complements any room interior

Specifications:

• General:
  • Item#: 5095184-00
  • Description: AKG CBL Series Professional Boundary Layer Microphones, Dual-Element
  • Model: CBL201-B
  • Polar Pattern: Cardioid
  • Minimum Current: 400 A
  • Maximum Current: 600 A
  • Typical Current: 500 A
  • Maximum SPL: 120 dB
  • LED: RGB ring LED to indicate mic status
• Audio Output:
  • Output Voltage: 3.3V (10%)
  • Output Max Current: 500 A (10%)
• Powering Input:
  • Input Max Voltage: 24V (+10%)
  • Input Min Voltage: 3.3V (-10%)
  • Input Resistance: 100 k
• Powering Interface:
  • Min Supply Voltage: 24V -10% (phantom power)
  • Max Supply Voltage: 48V -10% (phantom power)
  • Output Impedance: Maximum 200
• Design:
  • Finish: Black
  • Device: Boundary Layer Microphone
• Dimensions:
  • Height: 1.1″ (28.4mm)
  • Width: 5.1″ (128.5mm)
