Allen & Heath XONE:4D Universal DJ Controller

Allen & Heath XONE-4D DJ Mixer with Midi Control

Evolved from the, revolutionary XONE:3D, the class-leading Xone:4D is a unique performance DJ controller that enables the seamless integration of computer-based digital media into the traditional DJ workspace.

It combines a fully featured, high specification professional analogue DJ mixer with 105 MIDI controls and a 96 kHz 24-bit, 20-channel Allen & Heath-developed USB 2.0 soundcard. It enables DJs to greatly extend the capability of their digital setup, such as running 4 simultaneous decks in NI Traktor, or by being able to achieve genuine multi-track recording of their sets in applications such as Ableton Live or ProTools. The Xone:4D has been given Traktor Scratch approval by Native Instruments, enabling full compatibility with their encoded vinyl system.

The progressive XONE:4D has been developed in conjunction with some of the worlds most cutting-edge DJ/producers to become the ultimate cutting-edge DJ workstation.

Mixer:

• 4 multi-input stereo channels
• Switchable phono or line input stages, RIAA preamps on 3 channels
• Soundcard output routing switches for each channel
• 3-band total kill EQ +6dB to off
• 2 FX sends, FX1 with pre/post selection
• 2 analogue VCF filters – low, band & high-pass, resonance, frequency and on switch
• 2 stereo returns
• BPM LCD display
• Headphone monitor (3.5mm and 1/4″ sockets) with mix/cue control
• Assignable LFO and editable fader waveform function
• Mic input on XLR with level control and 2-band EQ, routable directly to soundcard

USB 2.0 Soundcard:

• 20 channel 96 kHz/24-bit USB 2.0
• PC and Mac drivers
• 10 in/10 out (4 analogue + 1 digital stereo inputs and outputs)
• Soundcard inputs fed from mic, FX1, FX2, main mix or stereo channels 1-4 pre or post fade

MIDI Control:

• Total of 227 mappable MIDI messages can be sent from select mixer controls
• Shift mode function for double layer
• Compatible with any PC software that has MIDI assignable functions
• 105 MIDI controls, including dedicated MIDI sections containing:
• 8x60mm linear faders
• 16 detented rotary pots
• 10 rotary encoders
• 50 switches
• 2 jog wheels
• 8 illuminated push switches
