Blackmagic Design Studio Camera 4K 2

Blackmagic Design Studio Camera 4K 2

The Blackmagic Studio Camera 4K is the live broadcast camerathats ready for multi camera Ultra HD production today. Featuring a massive 10 inch viewfinder, MFT lens mount, talkback, tally indicators, phantom powered microphone connections, 12G-SDIand user upgradeable optical fiber connections that let you connect to your switcher with a single cable! The advanced 4K model is switchable to 1080 HD, that means you can work in HD today and youre always ready for Ultra HD production.

Specifications:

Camera Features

• Effective Sensor Size: 13.056mm x 7.344mm
• Focus: Auto focus. Peaking mode
• Lens Mount: Active MFT Mount
• Lens Control: Iris, focus, zoom on supported lenses
• Dynamic Range: 11 Stops
• Screen Dimensions: 1 x 10.1 inch 1920 x 1200
• Screen Type: 10.1 inch – TFT-LCD
• Mounting Options: 2 x 3/8″ tripod mount. 4 x 1/4″”-20 UNC thread mounting points on top of camera. 3 x 1/4″ 20 UNC thread mounting points left on right of camera

Connections

• Total Video Inputs: 1 x SDI
• Total Video Outputs: 1 x SDI
• SDI Rates: 1.5G, 3G, 6G, 12G
• Optical SDI: Supports optional SMPTE optical module
• Optical Fiber Input/Outputs: 12G Optical Fiber Input and Output capable
• Optical fiber SFP module sold separately
• Analog Audio Inputs: 2 x XLR , phantom power
• Analog Audio Outputs: Aviation headphone jacks (Fixed Wing Plugs) output for talkback and audio monitoring
• Reference Input: Tri-Sync or Black Burst.
• SDI Audio Outputs: 2 channels in 12G-SDI 48Khz and 24 bit. 2 channels for talkback on channel 15 – 16
• Remote Control: 1 x 2.5mm LANC for Iris Control and Focus. SDI CCU control from ATEM
• Computer Interface: USB 2.0 Mini-B port for software updates

Audio

• Microphone: Integrated stereo microphone
• Built in Speaker: None

Standards

• SD Video Standards: None
• HD Video Standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94 and 1080i60
• Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94 and 2160p60
• SDI Compliance: SMPTE 292M, SMPTE 424M Level B, SMPTE 2081-1, SMPTE 2082-1
• SDI Audio Sampling: 48 kHz and 24-bit

Media

• Media: None
• Media Format: None

Supported Codecs

• Codecs: None

Control

• Controls: Push button controls for navigating menus
• External Control: Blackmagic SDI Control Protocol. 2.5 mm LANC connection for lens control

Color Corrector

• DaVinci YRGB

Talkback and Tally

• Live Tally Indicator: 1 x for talent, 1 x for operator
• Talkback: SDI Channels 15 and 16

Software

• Software Included: Blackmagic Camera Setup for Mac and Windows

Operating Systems

• Mac 10.11 El Capitan,
  Mac 10.12 Sierra or later.
• Windows 8.1 or Windows 10.

Power Requirements

• 1 x External 12V power supply

Optional Accessories

• SMPTE compatible SFP Optical Module
• Blackmagic Studio Camera 4K

Environmental Specifications

• Operating Temperature: 0 to 40 C (32 to 104 F)
• Storage Temperature: -20 to 45 C (-4 to 113 F)
• Relative Humidity: 0% to 90% non-condensing

What’s Included

• Blackmagic Studio Camera 4K
• Sun Shield and attachment screws
• Turret Dust Cap
• 12V AC Adapter
• SD card with software and manual

Warranty

• 12 Month Limited Manufacturer’s Warranty
