Elation Opto Branch 8 5-Pin 8-Way DMX Distributor

Elation Opto Branch 8 8-Way DMX Distributor

The Opto Branch is an 8-way 5-pin DMX opto isolator and distributor.

Features:

• 8 Way DMX data splitter
• Fully DMX-512 (1990) compliant
• Buffers and distributes DMX data reliably
• DMX status indicator
• 5 pin Neutrik XLR input and passive loop through
• 8, 5 pin Neutrik XLR, isolated outputs
• Input is isolated from all outputs
• All outputs are isolated from each other
• Power: Auto Switching, 100-240V 50/60Hz
• Powercon, power input
• On/Off power switch
• 1U 19″ rack mount
• Dimensions (L x W x H): 19″ x 1.75″ x 5.71″ (482.5 x 44.5 x 145mm)
• Weight: 4.4lbs (2kg)
