Elation Rayzor 360Z 3 x 60-Watt RGBW LED Moving Head Light
The Rayzor 360Z is a brilliant compact beam moving effect luminaire with 3 x 60W Osram RGBW LEDs. Features include 8 to 77 motorized zoom, fast and precise 16-bit continuous full 360 pan and tilt rotation, pixel control, adjustable color temperature (2,700K – 8,000K), electronic strobe, dimmer, and selectable dimming curve effects, DMX, RDM (remote device management), and Art-NET support, 5-pin XLR, RJ45 etherCON, and powerCon True1 in/out connections, (7) button control full color 180 reversible menu display, multiple unit power linking, flicker free operation for TV and film, and a multi-voltage universal auto switching power supply (100-240v).
Features:
- Compact beam moving effect luminaire with zoom
- 3 x 60W Osram RGBW LEDs
- Motorized zoom and pixel control: 8 to 77
- Fast and precise 16-bit continuous 360 pan/tilt rotation
- Linear color temperature presets (2,700 – 8,000K)
- Adjustable refresh rate frequency and gamma
- DMX, RDM, Art-NET, sACN support
Specifications:
- Light source: 3 x 60W Osram RGBW LEDs, 50,000 hour average LED life (LED life may vary depending on several factors including but not limited to:
- environmental conditions, power/voltage, usage patterns (on-off cycling), control, and dimming)
- Photometric data: 28,020 lux 2,603 FC @6.6 (2m) (8 min zoom) full on, 545 lux 51 FC @6.6 (2m) (77 max zoom) full on
- Beam angle zoom: 8 – 77
- Linear color temperature presets: 2,700 – 8,000K
- RGBW color mixing and pixel control
- 8 color presets
- 8 chase macros
- Electronic strobe and variable dimming curves
- DMX channel modes: 20, 26, 32
- Continuous pan and tilt movement: 360
- Adjustable refresh rate: 900-25,000 Hz
- Adjustable gamma brightness: 2.0, 2.2, 2.4, 2.8
- Button touch control panel: (6)
- 8 / 16 bit resolution adjustable movement
- Full color 180 reversible LCD menu display
- 5-pin XLR DMX in/out
- RDM (remote device management)
- RJ45 etherCON in/out (Art-NET, sACN)
- powerCon True1 power in/out
- Electrical / thermal: AC 100-240V – 50/60Hz
- Max power consumption: 300W
- Thermal: 5 F to 113 F / -15 C to 45 C
- Approvals / ratings: CE | RoHs | IP20
- Dimensions: 11.0″ x 7.9″ x 16.6″ / 280.6 mm x 199.5 mm x 422.1mm (LxWxH)
- Weight: 17 lbs. / 7.7 kg
