Electro-Voice EKX-15 Passive 15-in PA Speaker

Electro-Voice EKX-15 Passive 15-inch PA Speaker

Features:

• EKX-15: 1600 W (peak), 132 dB peak SPL utilizing high-sensitivity transducers designed and engineered by EV.
• EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.
• Lightweight, compact 15-mm wood enclosure with internal bracing, and durable EVCoat finish.
• Eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.
• 90 x 60 pattern for best coverage on mid-size stages. 40 monitor angle with rubber feet.

Specifications:

• Axial Sensitivity (SPL, 1 W @ 1 m): 96 dB Full Space Measurement
• Connector Type: Dual NL4
• Coverage (Nominal -6 dB) H: 90
• Coverage (Nominal -6 dB) V: 60
• Crossover Frequency: 1.6 k Hz
• Enclosure Material: 15 mm, plywood with EVCoat
• Frequency Response (-10 dB): 50 Hz – 20 k Hz Full Space Measurement
• Frequency Response (-3 dB): 75 Hz – 18 k Hz Full Space Measurement
• Grill: 18 AWG steel with powdercoat
• HF Transducer: DH-1M 1-inch titanium compression driver
• LF Transducer: EVS-15M 381 mm (15 in)
• Maximum SPL: 132 dB Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating
• Minimum Impedance: 7.2 Ohm
• Nominal Impedance: 8 Ohm
• Power Handling (Continuous/Peak): 400 W/1600 W
• Recommended High-Pass Frequency: 50 Hz
• Suspension: (8) M10 threaded mounting points
• Height: 16RU 685 mm (26.97″)
• Width: 432 mm (17.01″)
• Depth: 429 mm (16.89″)
• Weight: 23.2 kg (51.15 lbs.)
