ETC Source Four LED Series 2 Lustr, Light Engine Only

ETC Source Four LED Series 2 Lustr, Light Engine Only

The Four LEDSeries 2 Lustr comes with one of the following connectors: Bare End, Edison, Twist Lock, or Stage Pin.

The Four LED Series 2 Lustr luminaires are based on the x7 Colour System, utilising seven colours including high-output lime to achieve true, usable broad-spectrum colour with a depth and feel beyond any RGB fixture. ETC also offers a special LED-only version of the 50 lens tube.

The Four LED Series 2 Lustr is available in black, white or silver.

Features:

• 60 Luxeon Rebel LED emitters
• 20,000-hour LED life
• Patented x7 Colour System array
• Includes slots for glass or stainless steel gobopatterns and soft focus diffuser media
• Accessory slot for motorised pattern devices oroptional iris
• Power in/thru via PowerCon connections
• Up to three fixtures can be linked in via powerin/thru connectors (four total fixtures per circuit)
• DMX512-A/RDM in/thru via five-pin XLR connectors
• Multiple control options, including RGB, strobe, andconsole-free Primary/Secondary mode
• 15-bit virtual dimming engine for smooth fades andminimal colour shift during dimming
• CE compliant; IP20 rated
• Available in black (standard), white or silver grey (optional) or custom colours by request

Specifications:

• General:
  • 60-LED array
  • ETL listed to UL1573 the standard for stage and studio lighting units
  • IP20-rated for indoor use
  • Power and DMX in/thru connections for easy setup
  • User-friendly control interface with multiple modes and fixture settings
• Physical:
  • Rugged die-cast all-metal housing
  • Available in black (standard), white or silver gray (optional) or custom colors (contact factory)
  • C-clamp
  • Positive-locking double-clutch fixture body
  • Slot for glass or stainless steel patterns and softfocus diffuser
  • Wide accessory slot with sliding cover for motorized pattern devices or optional iris
  • Hanging yoke standard. Optional yoke/floor stand available
• Electrical:
  • 100VAC to 240VAC 50/60 Hz universal power input
  • Neutrik power in and thru connections
  • Up to three fixtures (15A max) may be linked via power thru connector (four fixtures total per circuit)
  • Requires power from a non-dim source
• LED:
  • 20,000-hour LED life (20,000 hours to 70% intensity)
  • 60 Luxeon Rebel LED emitters
• Colour:
  • Exclusive x7 Colour System seven-colour LED array
  • Beautifully illuminates skin tones and other objects for natural appearance and high colour rendering
  • Broad-spectrum colour interacts seamlessly with conventional sources
  • Exclusive optional red-shift option emulates tungsten dimming performance
• Optical:
  • Use the included soft-focus diffuser for creating washes or soft light
  • Best performance using ETCs EDLT lens tubes
  • Can use all ETC Source Four interchangeable lens barrels: 5, 10, 14, 19, 26, 36, 50, 70, and 90 field angles, as well as 19, 26, 36, and 50 EDLT lenses
  • For better performance, use the LED 50 barrel
• Control:
  • DMX512 in and thru via five-pin XLR connectors
  • Multiple control options, including RGB, strobe, and console free Primary/Secondary mode
  • 15-bit virtual dimming engine provides smooth,high-quality theatrical fades and minimizes colour shift during dimming
  • RDM functionality for address and setting changes
• Thermal:
  • Ambient operating temperature of 32 to 104F (0 to40C)
  • A ctive electronic thermal management for droop-free operation
  • Quiet fan cooling
  • Fixture is designed for continuous operation up to 104F (40C) ambient temperature and requires free flow of air around fixture housing
• Weight:
  • With Barrel: 18.3 lbs (8.3 kgs)
  • Without Barrel: 14.3 lbs (6.5 kgs)
