ETC Source Four Mini LED with Shutter Barrel – 3000 K/90+ CRI

ETC Source Four Mini LED with Shutter Barrel – 3000 K/90+ CRI

The Source Four Mini LED delivers lighting in a remarkably compact shell.

This LED combines the optics and intuitive controls of the Source Four with advanced LED technology, measuring just one-third the size of the original.

The Source Four Mini LED features 3000 K colour temperature with 90+ CRI for accurate colour rendering. Also, it offers four selectable field angles to suit diverse applications.

The Source Four Mini LED is available as portable, ceiling-mount canopy, or track-mount configurations to integrate seamlessly into your rig. It is also available in black, silver or white.

Features:

• Rugged, die-cast fixture body
• Interchangeable lens tubes permit selection of 19, 26, 36 and 50 field angles
• Unique, efficient optical system
• Long-life dimmable white LED source in two CRI values:
  • Source Four Mini LED Gallery: 90+ CRI
• Three-plane shutters
• Multiple accessories available for colour, gobo pattern, and filtering purposes
• Multiple mounting options: clamp, canopy and 3-circuit Eutrac (or Eutrac compatible track – consult vendor)
• ETC design colour black

Specifications:

• Physical:
  • Die-cast aluminium construction (A380 grade)
  • Fine-texture, high-temperature powder-coated paint
  • Steel yoke with 10.3mm diameter mounting hole
  • Rotating shutter assembly 175
  • E-size gobo pattern holder (included): 37.5mm with a 25.4mm image area
  • Stainless steel shutters in a tri-plane assembly
  • Fixed-beam angles to suit a range of throw distances
  • Tool-free tilt and beam adjustment
  • High-impact resistant, thermally insulated knobs and shutter handles
  • Captive accessory slot for pattern holder (included)
  • Dual captive accessory slots for media frame (included)
  • Portable:
    • Yoke-mounted LED driver in colour-matched enclosure
    • 1.8m power cable with UK or Schuko/NF connector
  • Black or white power lead
• Electrical:
  • Power at full intensity: 12W typical, 14W max
  • Input voltage 190-250V, 50/60Hz
  • Dimmable (forward and reverse phase)
  • Inrush current at 230V: 4A
  • CE compliant
• LED Engine:
  • Cree LED (90+ CRI)
  • Long-life: 35,000 hours L70 lumen maintenance
  • 3000K colour temperature options
• Optical:
  • 19, 26, 36 and 50 field angle Lens Tubes available
  • Projector-quality, high-contrast lenses
  • Beam edge continually adjustable hard to soft edge
• Thermal: 0C to +40C ambient operating environment
