Hertz Capri HBB Digital Hidden Marine Source Unit

Source Units
The CAPRI HBB is the black box version of the renowned Hertz CAPRI marine source, delivering the same high-resolution audio performance and advanced features without an integrated display. Designed for seamless control via remote units, Bluetooth app, or NMEA 2000, it ensures full management of four independent zones with dedicated subwoofer outputs. Engineered to withstand harsh marine environments, the CAPRI HBB offers superior connectivity, including Bluetooth 5.1, USB, digital inputs/outputs, and DAB+ readiness, for an audiophile-grade marine experience.

Features:

• Native DSP working at 24 bit/96 kHz and an extended audio band up to 40 kHz for hi-res audio performance.
• CAPRI BB is designed to play 24-bit/96 kHz hi-res audio for audiophile sound.
• CAPRI BB features 4 pairs of stereo outputs each with independent subwoofer output providing the ability to create 4 independently controlled listening areas to obtain the perfect sound everywhere.
• The powerful 8-band digital equalizer will support you in finding the best sound.
• Customize the sound with 8 EQ presets created by Hertz audio engineer.
• Voltage indicator to check battery status.

Specs

Specification
PEAK POWER @ 4 CLASS-D: 4 x 70 W
FRONT PANEL IP RATING IP67
MULTI-ZONE 4
LINE OUT (RCA) 4x L+R (one per zone) – HPF: ALL, 60, 80, 100 Hz
SUBWOOFER OUT (RCA) 4x (LPF: ALL, 60, 80, 100 Hz)
AUX INPUT (RCA) 1x L+R
S/PDIF DIGITAL IN Toslink (24 bit/96 kHz)
S/PDIF DIGITAL OUT Coaxial (24 bit/96 kHz)
EQUALIZER CUSTOM 8 BANDS for each zone
EQ. PRESET 8
CAMERA IN Yes
BATTERY VOLTAGE GAUGE Yes

Size & Mounting
Unit Size mm (in.) W 146 (5.748) x H 105 (4.134) x D 121 (4.763)
Mounting Hole size mm (in.) W 122 (4.8) x H 52 (2.05)
Mounting Depth mm (in.) 99 (3.89
Mounting Method Panel mount (4 screws)

Sources
TUNER AM/FM (RDS) (EU/US) Weather band
USB Yes (2A)
IPOD/IPHONE Yes
DAB+ Ready
SIRIUSXM READY Yes
BLUETOOTH 5.1
Audio streaming with ID3 Tag Display
LDAC AAC APTX HD
REMOTE CONTROL HMC HD1 (up to 4 zones) HMC U1 (up to 2 zones)
