Martin JEM Compact Hazer Pro 120V DMX Haze Machine

Martin JEM Compact Hazer Pro 120V DMX Haze Machine

Robust yet small and lightweight, the Jem Compact Hazer Pro is a versatile haze machine designed for the highly demanding professional market. Its ability to produce exceptional atmospheric haze effects in a short period of time while operating at low noise levels make it ideal for nearly any application from shows and events to theatre, TV studios, clubs, cruise ships, theme parks and more.

Features:

• Finest haze production in its class
• Small particle, even haze
• Continuous output
• 1 minute heat up time
• Water-based fluid with long hang time
• Low noise
• Lightweight
• Optical Density Timer Control system (ODTC)
• Variable haze and fan controls with 5% increments
• 2.5 liter fluid capacity
• Max operating time at min output (2.5 L) – 70 hours
• Sealed fluid system for transportation
• Advanced Pump Technology (APT)
• Shutdown with automatic start-up cleaning mode (if shutdown not performed correctly)
• Shutdown button prevents clogging
• RDM ready
• On-board DMX 5pin
• User-friendly on-board control panel

Specifications:

Performance

• Coverage volume: 3800 m3 per minute
• Maximum operating time at minimum output with 2.5 l fluid: 70 Hours
• Operating time: Continuous
• Warm-up time (approx.): 1 minute

Control and Programming

• Control options: Onboard digital control panel with 4 digit display
• Control options: Continuous or timer-controlled output, 0-100% adjustable output level
• Control options: Adjustable fan speed level, 0-100%
• DMX channels: 3 (Haze, Fan, Special functions)
• RDM: RDM Ready

Construction

• Housing: Steel and aluminum
• Heat exchanger: 900 W

Fluid System

• Fluid pump: Oscillating piston, high pressure
• Onboard fluid capacity: 2.5 l
• Compatible Fluids: Jem C-Plus Haze Fluid only

Installation

• Orientation: Floor or optional flying kit

Connections

• Power connection: Neutrik PowerCon
• DMX data: 5-pin XLR
• Remote control: 3-pin locking XLR

Electrical

• AC power (EU models): 220-240 V nominal, 50 Hz
• AC power (US models): 110-120 V nominal, 60 Hz
• Main fuse (220-240 V power): 6.3 AT
• Main fuse (110-120 V power): 10 AT

Thermal

• Maximum ambient temperature (Ta max.): 40 C
• Exterior surface temperature, steady state: 30 C
• Max. nozzle temperature: 290 C

Physical

• Length: 532 mm
• Width: 224 mm
• Height: 278 mm
• Dry weight: 8.5 kg
