Martin Rush FiberSource 1 LED Fiber Projector
A highly anticipated update to the FiberSource QFX 150, the new Rush FiberSource 1 is a powerful tool for illuminating fiber optic cables in permanent installations. With a new 78 W LED fiber projector, the Rush FiberSource 1 boasts improved efficiency and reliability while retaining all the key features of its predecessor, such as nine interchangeable colors, a twinkle effects wheel, electronic dimming and DMX/stand-alone control.
Features:
- 78 W LED fiber projector
- 9 interchangeable colors
- 0-100% electronic intensity control
- Twinkle effect wheel
- DMX or stand-alone control
- Up to 300 fiber cables (1 mm)
Specifications:
Physical
- Length: 305 mm (12.0 in.)
- Width: 210 mm (8.3 in.)
- Height: 200 mm (7.9 in.)
- Weight: 7.6 kg (16.8 lbs.)
Dynamic Effects
- Color wheel: 9 interchangeable filters + open, indexing, continuous rotation
- Twinkle effect: Continuous rotation, variable speed and direction
- Dimmer: 0 – 100% continuous dimming
Control and Programming
- Control options: DMX, standalone, master/slave
- DMX channels: 5
- Standalone programming: DIP switch
- Settings and DMX addressing: DIP switch
- DMX compliance: USITT DMX512/1990
Optics
- Light source: CREE 78 W LED
- Color temperature: 60007000 K
- CRI (color rendering index): >70
- Minimum LED lifetime: 35 000 hours (to >70% luminous output)*
*Figure obtained under test conditions
Construction
- Color: Black (RAL 9005)
- Housing: Steel and aluminum
- Protection rating: IP20
Installation
- Mounting points: Four rubber-mounting grommets, two 13 mm holes for rigging clamps
- Location: Indoor use only, must be fastened to surface or structure
- Minimum distance to combustible materials: 0.2 m (7.9 in.)
- Minimum clearance around fans and vents: 0.1 m (4.0 in.)
- Orientation: Any
Connections
- AC power in/out: Neutrik PowerCon
- DMX data in/out: 3-pin and 5-pin locking XLR
Electrical
- AC power: 100-240 V, 50/60 Hz
- Power supply unit: Auto-ranging electronic switch-mode
Typical Power and Current
- 110 V, 60 Hz: 0.8 A, 87 W, PF 0.986
- 230 V, 50 Hz: 0.5 A, 86 W, PF 0.909
Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Thermal
- Cooling: Forced air (regulated, low noise)
- Maximum ambient temperature (Ta max.): 40 C (104 F)
- Minimum ambient temperature (Ta min.): 5 C (41 F)
- Maximum surface temperature, steady state, at 40 C ambient: 50 C (122 F)
Approvals
- EU Safety: EN 60598-2-1
- EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61547
- US Safety: ANSI/UL 1598
- US EMC: 47 CFR Part 15 Class A
- Canadian Safety: CSA C22.2 No. 250.0
- Australia/NZ: C-TICK N4241
Included Items
- Power cable, 1.5 m (4.9 ft.), without mains plug:
- Color filter M05, blue 108L w. adaptor:
- Color filter M05, yellow 603L w. adaptor:
- Color filter M05, green 206L w. adaptor:
- Color filter M05, red 308L w. adaptor:
