Martin SM850 850-Watt Fog Machine with Remote

Martin SM850 850-Watt Fog Machine with Remote

The highly anticipated replacement of the Magnum 850, the RUSH SM 850, is one of several products in a brand new line of atmospheric effects from RUSH by Martin. The RUSH SM 850s clean industrial design is complemented by market-leading features including a 4-channel wireless remote control system and a blue LED-illuminated fluid container with a rear-view level indicator and a carrying handle for easy transportation. An ideal companion for mobile DJs and bands and effective in small nightclubs that require high output at an attractive price point.

Features

• 850 W heater element
• 200 m3 per minute output
• 8-minute heat-up time
• 1.6-liter fluid capacity
• Blue LED-illuminated fluid container with level indicator
• Rugged carrying handle
• Steel housing
• 4-channel wireless and wired remote control
• Handheld remote control

Technical Specifications

• Length: 411 mm (16.2 in.)
• Width: 294 mm (11.6 in.)
• Height: 309 mm (12.2 in.)
• Weight: 7.3 kg (16 lbs.)
• Maximum smoke output* : 200 m3 per minute
• Maximum operating time at full output*: 20 seconds
• Warm-up time*: 8 minutes
• *Figures are approximate:
• Control options: Dedicated wired / 4-button wireless remote control
• Color: Black
• Housing: Steel and aluminum
• Protection rating: IP20
• Pump: Oscillating piston, high pressure
• Fluid capacity: 1.6 l (0.42 gal.)
• Consumption at peak output: 60 ml per minute
• Mounting: Adjustable bracket, surface or truss mount
• Orientation: Up to +/- 45 from horizontal
• Location: For indoor use only
• Minimum distance to combustible materials: 1 m (39.4 in.)
• Minimum clearance around vents: 0.5 m (19.7 in.)
• AC power in: IEC
• Wired remote control: 5-pin DIN
• Wireless remote control receiver: 5-pin DIN
• AC power, EU model: 220-240 V nominal, 50 Hz
• AC power, US model: 100-120 V nominal, 60 Hz
• 100 V, 60 Hz: 950 W, 9.0 A
• 120 V, 60 Hz: 950 W, 7.5 A
• 240 V, 50 Hz : 900 W, 3.8 A
• Maximum ambient temperature (Ta max.): 40 C (104 F)
• Minimum ambient temperature (Ta min.): +5C (41F)
• Exterior surface temperature, steady state: 50C (122F)
• Maximum nozzle temperature: 300 C (572F)
• EU model:
• EU safety: EN 60355-1, EN 62233, EN 62479
• EU EMC: EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-3
• EU RTTE (wireless remote): EN 60950-1, EN 300220-1, EN 300220-2, EN 301489-1, EN
• 301489-3
• Australia/NZ: C-TICK N4241
• US model (certification pending):
• US safety (pending): UL 499
• US EMC: FCC Part 15 Class A
• US EMC (wireless remote): FCC ID 2AEYKSMWIRELESS
• Canadian safety (pending): CSA C22.2 No. 64

Included Items

• User manual
• 1.5 m power cable (no mains plug on EU model)
• 4.5 m wired remote control
• 4-channel wireless remote control and receiver
