A pair of new front speakers and a subwoofer is one of the most common aftermarket audio upgrades. The link500.4mini is the perfect amplifier for this application. When used in 3-channel mode, the amplifier can produce 125 watts x 2 for the main speakers and 250 watts x 1 for the subwoofer, so it wont lack for power. Speaking of the subwoofer, channels 3/4 have a 1-band PEQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance.
The link500.4mini has our new adaptive loading technology plus the ability to handle up to 40V of hi-level input. It also has fully adjustable high and low pass crossovers. For factory audio systems where no full-range signal is present, the link500.4mini has built-in summing, so it can handle that internally, without the need for an outboard processor. Like all Wvtech amplifiers, the link500.4mini is start/stop system compatible.
Specs
500 Watt 4-Channel Amplifier
75 watts x 4 @ 4 ohms
125 watts x 4 @ 2 ohms
250 watts x 2 @ 4 ohms BTL
Small Footprint Only 9.2×4.5×1.65
Adjustable Paragraphic EQ (Channels 3/4)
Variable Subsonic Filter (Channels 3/4)
Variable Hi/Low Pass Crossover (-12dB/oct)
Remote Level Control (RLC) w/Optional linkRC (CH 3/4)
Built-In Summing w/Level Trim Adjsutment
Parametric EQ (CH 3/4)
Active Thermal Management
Start/Stop Sytem Compatiable
Adaptive OEM Load Technology
40V Input Capabilty
Differential Balanced Inputs
Variable Gain Adjustment w/Clip LED
Auto Turn-On via DC-Offset or Audio Signal Detect
Locking Detachable Hi-Level Speaker Terminals
4 Gauge Power/Ground Terminals
Professional Grade Panel Mount RCAs
Compact Aluminum Chassis w/Detachable Mounting tabs
lin500.4mini Specifications
Input Sensitivity
SPK ————————— 1-20Vrms, 2-40Vrms
RCA ————————— 0.2V-5Vrms, 0.4V-10Vrms
Max Input Voltage (SPK) —— 40Vrms
Frequency Response ———– <10Hz to >43kHz (+0/-3dB)
THD+N ——————————- <1% at rated power
S/N ————————————- >85dBA (1W, 4)
