Wavtech link700.4plus 700 Watt 4 Channel Amplifier

The Wvtech mini series amplifiers pack an incredible amount of power and features into an extremely small package. Still, with a width of only 4.5, there are some limitations. That is where the plus series comes in. While still incredibly small at just 5.5 wide, that extra 1 opens up some interesting possibilities. Introducing the link700.4plus.

The link700.4plus is the most versatile 4-channel amplifier available. Like our mini series multi-channel amplifiers, the plus series models have built-in summing. But with the additional width, we can now accommodate 6-channels of input. That means you can sum a 3-way OEM system and get front and rear full-range output, plus an RCA Pre-Out for a subwoofer amplifier. It is powerful, producing 100 watts x 4 RMS @ 4 ohms, or 175 watts RMS x 4 @ 2 ohms. In BTL mode the power is 350 watts x 2 RMS @ 4 ohms.

The link700.4plus has our bassFREQ processor, with 24 dB/octave lowpass and subsonic filters, as well as a fully adjustable 1-band parametric EQ. The optional RLC can be configured to control channels 3/4 when in lowpass mode, or the RCA Pre-Out.

Specs

700 Watt 4-Channel Amplifier

100 watts x 4 @ 4 ohms

175 watts x 4 @ 2 ohms

350 watts x 2 @ 4 ohms BTL

Small Footprint Only 10.25×5.5×1.65

Variable HP Crossover (-12dB/oct) with 1x/10x CH1/2

Variable HP/BP/LP Crossover (-12dB/oct) CH3/4

Variable LP Crossover (-24dB/oct) RCA Pre-Out

Variable Subsonic Filter (-24dB/oct) RCA Pre-Out

Adjustable Parametric EQ RCA Pre-Out

Remote Level Control (RLC) w/Optional linkRC (Channels 3/4 or RCA Pre-Out)

bassFREQ Bass Processor w/Parametic EQ (CH 3/4 or Pre-Out)

Active Thermal Management

Start/Stop System Compatible

Adaptive OEM Load Technology

40V Input Capability

Differential Balanced Inputs

Variable Gain Adjustment w/Clip LED

Auto Turn-On via DC-Offset or Audio Signal Detect

Locking Detachable Hi-Level Speaker Terminals

4 Gauge Power/Ground Terminals

Professional Grade Panel Mount RCAs

Compact Aluminum Chassis w/Detachable Mounting tabs

link700.4plus Specifications

Input Sensitivity

SPK ————————— 1-20Vrms, 2-40Vrms

RCA ————————— 0.2V-5Vrms, 0.4V-10Vrms

Max Input Voltage (SPK) —— 40Vrms

Frequency Response ———– <10Hz to >45kHz (+0/-3dB)

THD+N ——————————- <1% at rated power

S/N ————————————- >80dBA (1W, 4)
