Yamaha PY64-D Dante Interface 64×64 Expansion Card with SRC for DM7 Mixers

Yamaha PY64-D Dante Interface Card with SRC

The PY64-D expands the Dante connection on the DM7 Series with sample rate converter (SRC) functions, ensuring straightforward connections for complex systems, including devices using different sample rates. By connecting the DM7 Series built-in Dante connectors and those on the PY64-D card to different Dante networks, the DM7 console can be used as a bridge between them, providing a secure option. It features 64 inputs and 64 outputs at 96 kHz with both synchronous and asynchronous SRC modes available. The SRC setting is available from the console, and the redundant connections are supported with primary and secondary connectors.

Features

• Provides 64in/out at 96kHz with SRC
• Both synchronous and asynchronous SRC options available, ensuring straightforward connections for complex systems and devices using different sample rates
• SRC settings available directly from the console GUI
• Redundant connections are supported with primary and secondary connectors
• Daisy chain connections are also supported

PY64-D SPECIFICATIONS

• Dante Clock
• 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz (4%/0.1%/+0.1%/+4.167%)
• Sampling Rate Converter
• From 44.1 kHz 4% to 96 kHz +4.167%
• Operating Temperature Range
• 32 to 104 degrees F (0 to 40 degrees C)
• Storage Temperature Range
• -4 to 140 degrees F (-20 to 60 degrees C)
• Terminal
• PRIMARY , SECONDARY
• Format
• Dante
• Data Length
• 24-bit / 32-bit*1
• Level
• 1000BASE-T
• Audio
• 64×64
• Connector
• etherCON CAT5e *2 *3
• Power Consumption
• 5.5 W
• Dimensions (W x H x D)
• 3.94 inches 1.57 inches 5.31 inches
• Net Weight
• .66 lbs.

*1 Features a sampling rate converter. Supported data length: 24-bit only Supported frequency: From 44.1 kHz 4% to 96 kHz +4.167%

*2 CAT5e or higher cable is used for connection.

*3 STP cable is recommended for connection.
