Yorkville CM5-70 Coliseum Mini Install Speaker
The CM5/70 is a 30W 5″ high performance ceiling mount loudspeaker. Ideal for any background music or paging system where superior sound quality is a priority, this speaker is made for louder club or restaurant / retail environments.
Built in 70-volt taps at 5W, 10W or 20W as well as optional 8-ohm (30W) operation means that virtually any amplification or paging system, including the Coliseum CA1 or CA1T can drive the CM5/70.
Features:
- 5″ high performance flush mount ceiling speaker
- Selectable 70V or 8-ohms operation
- Power taps at 5W, 10W and 20W
- 30W (8-ohms mode)
- Open back design
- mounting hardware included
Specifications:
- System type: passive ceiling speaker
- Program Power: 30W
- Nominal impedance: 8 ohms/ 70V transformer
- Sensitivity: 91 dB @1W/1m
- Frequency response (Hz +/- 3dB): 150 – 20k
- Driver configuration: single 5″
- HF dispersion: 90 x 90 (H x V)
- Inputs: screw terminal solder lugs
- Enclosure materials: ABS plastic
- Grill: perforated metal
- Wiring: 5W (blue), 10W (yellow), 20W (red) for 70V operation
- Dimensions: 8″ x 3″ / 20 cm x 7.6 cm
- Weight: 3.0 lbs. / 1.4 kg
