Yorkville YX10SP 10-Inch Powered Subwoofer

Yorkville YX10SP 10-Inch Powered Subwoofer

The ultra compact 200-watt YX10SP is the perfect subwoofer solution for small live sound or PA installations where additional low frequency support is needed. Designed to be the ideal companion for the YX10P powered full range cabinet, the YX10SP uses a high efficiency front mounted 10-inch woofer to deliver solid, even bass response.

Designed for ease of use in virtually any application, YX Series powered subwoofers use proven amplifier topologies, integrated crossovers and innovative input design that allow direct connection to line or speaker level sources.

Integrated pole mount adaptor allows full range loudspeakers like the to be raised above the crowd easily and effectively with a simple subwoofer stand or speaker pole.

Designed with working musicians in mind, the YX subwoofers use all metal bar handles, metal input plate, integrated speaker mounts and a custom punched, perforated metal grille to protect the speaker.

Features:

• 200-Watt integrated Class-D amplifier
• 10″ long excursion woofer
• Maximum SPL: 120dB (continuous)
• Integrated 80Hz crossover outputs
• Balanced inputs and outputs
• Integrated bar handles & top speaker mount

Specifications:

• System type: subwoofer
• Active powered subwoofer
• Program power: 200-Watts
• Max SPL: 120 dB (continuous)
• Frequency response (Hz +/- 3dB): 50-150Hz
• Crossover frequency: 80Hz
• Driver configuration: 10″ ceramic
• Inputs: 1 x combi-jack (l/mono) 1 x XLR (right)
• Mixer controls: gain control, ground lift, integrated crossover (80Hz High Pass Output for Top Cabinets)
• Features: 2 x XLR link thru / 2 x XLR high pass (80Hz crossover)
• Corners: metal
• Feet: rubber
• Bar handles: 2 (sides)
• Pole mount adapter: top, 1 3/8″-3.5cm
• Enclosure materials: MDF
• Baffle material: MDF
• Grille: custom punched black perforated metal
• Finish: black ozite
• Dimensions: 16.5″ x 18.5″ x 13.25″ / 41.9cm x 47cm x 33.7cm
• Weight: 38 lbs. / 17.3 kg.
