Yorkville YX12 12″ 200W 2-Way Passive Speaker

$149.00 $379.00

  • Unconditional Satisfaction Guarantee
  • No Shipping Fees Above 30
  • 2 Months to Decide. Returns Simplified.
SKU: MVK600341024

Yorkville YX12 12″ 200W 2-Way Passive Speaker

The YX12 delivers outstanding performance in a highly versatile full range loudspeaker. Engineered in North America, the YX12 benefits from Yorkville’s forty plus years of PA enclosure design experience in the creation of this compact general-purpose passive loudspeaker enclosure.

The YX12 cabinet uses a single 12-inch driver and an injection molded 90 x 40 degree horn with 1-inch throat and 1.4-inch Celestion neodymium compression driver. Yorkvilles tried and true dual-bulb CTL protection system protects the horn drivers aluminum diaphragm ensuring unmatched reliability in the field. The YX12 is built road-ready with easy-to-clean, durable black carpet covering, solid internal plywood bracing and reinforced internal component mounts.

Designed with working musicians in mind, the YX12 offers rugged 5/8-inch plywood cabinet construction, all metal bar handles, metal input plate, integrated speaker mounts and a custom punched, perforated metal grille to protect the speaker components. A modified trapezoidal shape ensures the YX12 can function equally as well as a front-of-house or monitor speaker.

Specifications:

  • System Type: 2-Way
  • Active or Passive: Passive
  • Program Power (Watts): 200
  • Biampable: No
  • Nominal Impedance (Ohms): 8
  • Sensitivity (dB @1Watt/1m): 99
  • Max SPL (dB): 122
  • Frequency Response (Hz +/- 3db): 65 – 20k
  • Crossover Frequency (Hz): 1800
  • Driver Configuration: 12 inch / 1.4 inch
  • HF Driver(s): 1.4 inch Aluminum (1 inch Throat)
  • HF Horn Injection Molded: ABS
  • HF Dispersion (H x V): 90 x 40
  • HF Protection: CTL
  • LF Driver(s): 12 inch Ceramic
  • LF Program Power(Watts): 200
  • Inputs – 1/4″ Jacks: 2
  • Inputs – Speakon 4-pin: 2
  • Corners: Metal
  • Feet: Plastic Glides
  • Bar Handles: 2 (Side)
  • Pole Mount Adapter (1 3/8″-3.5cm): Yes
  • Enclosure Materials 15mm (5/8inch): Plywood
  • Grille: Custom Punched Black Perforated Metal
  • Covering / Finish: Black Ozite
  • Dimensions (DWH xbackW, inches): 13.75 x 18 x 25.5 x 8.5
  • Dimensions (DWH xbackW, cm): 34.9 x 45.7 x 64.8 x 21.6
  • Weight (lbs/kg): 37 / 16.8
