Yorkville YX18S 18″ 400W Passive Subwoofer
The passive YX18S uses the tried and true vented 18-inch front loaded bass reflex subwoofer design. The internal passive crossover allows the 400-watt YX18S to be added to any system without additional external processing.
Solid plywood cabinet construction ensures the YX18S will remain rattle and buzz-free at the high volumes a subwoofer must endure. Integrated pole mount adaptor allows full range loudspeakers like the YX15 or YX15P to be raised above the crowd easily and effectively with a simple subwoofer stand or speaker pole.
Designed with working musicians in mind, the YX18S offers rugged 5/8-inch plywood cabinet construction, all metal bar handles, metal input plate, integrated speaker mounts and a custom punched, perforated metal grille to protect the speaker.
Specifications:
- System Type: Subwoofer
- Active or Passive: Passive
- Program Power (Watts): 400
- Nominal Impedance (Ohms): 6
- Sensitivity (dB @1Watt/1m): 98
- Max SPL (dB): 124
- Frequency Response (Hz +/- 3db): 45 – 150
- Crossover Frequency (Hz): 150
- LF Driver(s): 18 inch
- LF Program Power(Watts): 400
- Inputs – 1/4″ Jacks: 2
- Inputs – Speakon 4-pin: 2
- Other Controls / Features: Built-in passive low-pass filter for Plug-and-play simplicity
- Corners: Metal
- Feet: Plastic Glides
- Wheels: No
- Bar Handles: 2 (Side)
- Pole Mount Adapter (1 3/8″-3.5cm): Yes (Top)
- Enclosure Materials 15mm (5/8inch): Plywood
- Grille: Custom Punched Black Perforated Metal
- Covering / Finish: Black Ozite
- Dimensions (DWH xbackW, inches): 26 x 22 x 25
- Dimensions (DWH xbackW, cm): 66 x 55.9 x 63.5
- Weight (lbs/kg): 74 / 33.6
